Get Started with LiteRT-LM on Android

The Kotlin API of LiteRT-LM for Android and JVM (Linux, MacOS, Windows) with features like GPU and NPU acceleration, multi-modality, and tools use.

Introduction

Here is a sample terminal chat app built with the Kotlin API:

import com.google.ai.edge.litertlm.*

suspend fun main() {
  Engine.setNativeMinLogSeverity(LogSeverity.ERROR) // Hide log for TUI app

  val engineConfig = EngineConfig(modelPath = "/path/to/model.litertlm")
  Engine(engineConfig).use { engine ->
    engine.initialize()

    engine.createConversation().use { conversation ->
      while (true) {
        print("\n>>> ")
        conversation.sendMessageAsync(readln()).collect { print(it) }
      }
    }
  }
}

Demo for the Kotlin sample code

To try out the above sample, clone the repo and run with example/Main.kt:

bazel run -c opt //kotlin/java/com/google/ai/edge/litertlm/example:main -- <abs_model_path>

Available .litertlm models are on the HuggingFace LiteRT Community. The above animation was using the Gemma3-1B-IT.

For Android sample, check out the Google AI Edge Gallery app.

Getting Started with Gradle

While LiteRT-LM is developed with Bazel, we provide the Maven packages for Gradle/Maven users.

1. Add the Gradle dependency

dependencies {
    // For Android
    implementation("com.google.ai.edge.litertlm:litertlm-android:latest.release")

    // For JVM (Linux, MacOS, Windows)
    implementation("com.google.ai.edge.litertlm:litertlm-jvm:latest.release")
}

You can find the available versions on Google Maven in litertlm-android and litertlm-jvm.

latest.release can be used to get the latest release.

2. Initialize the Engine

The Engine is the entry point to the API. Initialize it with the model path and configuration. Remember to close the engine to release resources.

Note: The engine.initialize() method can take a significant amount of time (e.g., up to 10 seconds) to load the model. It is strongly recommended to call this on a background thread or coroutine to avoid blocking the UI thread.

import com.google.ai.edge.litertlm.Backend
import com.google.ai.edge.litertlm.Engine
import com.google.ai.edge.litertlm.EngineConfig

val engineConfig = EngineConfig(
    modelPath = "/path/to/your/model.litertlm", // Replace with your model path
    backend = Backend.GPU(), // Or Backend.NPU(nativeLibraryDir = "...")
    // Optional: Pick a writable dir. This can improve 2nd load time.
    // cacheDir = "/tmp/" or context.cacheDir.path (for Android)
)

val engine = Engine(engineConfig)
engine.initialize()
// ... Use the engine to create a conversation ...

// Close the engine when done
engine.close()

On Android, to use the GPU backend, the app needs to request the depending native libraries explicitly by adding the following to your AndroidManifest.xml inside the <application> tag:

  <application>
    <uses-native-library android:name="libvndksupport.so" android:required="false"/>
    <uses-native-library android:name="libOpenCL.so" android:required="false"/>
  </application>

To use the NPU backend, you might need to specify the directory containing the NPU libraries. On Android, if the libraries are bundled with your app, set it to context.applicationInfo.nativeLibraryDir. See LiteRT-LM NPU for more details about the NPU native libraries.

val engineConfig = EngineConfig(
    modelPath = modelPath,
    backend = Backend.NPU(nativeLibraryDir = context.applicationInfo.nativeLibraryDir)
)

3. Create a Conversation

Once the engine is initialized, create a Conversation instance. You can provide a ConversationConfig to customize its behavior.

import com.google.ai.edge.litertlm.ConversationConfig
import com.google.ai.edge.litertlm.Message
import com.google.ai.edge.litertlm.SamplerConfig

// Optional: Configure the system instruction, initial messages, sampling
// parameters, etc.
val conversationConfig = ConversationConfig(
    systemInstruction = Contents.of("You are a helpful assistant."),
    initialMessages = listOf(
        Message.user("What is the capital city of the United States?"),
        Message.model("Washington, D.C."),
    ),
    samplerConfig = SamplerConfig(topK = 10, topP = 0.95, temperature = 0.8),
)

val conversation = engine.createConversation(conversationConfig)
// Or with default config:
// val conversation = engine.createConversation()

// ... Use the conversation ...

// Close the conversation when done
conversation.close()

Conversation implements AutoCloseable, so you can use the use block for automatic resource management for one-shot or short-lived conversations:

engine.createConversation(conversationConfig).use { conversation ->
    // Interact with the conversation
}

4. Sending Messages

There are three ways to send messages:

sendMessage(contents): Message: Synchronous call that blocks until the model returns a complete response. This is simpler for basic request/response interactions.
sendMessageAsync(contents, callback): Asynchronous call for streaming responses. This is better for long-running requests or when you want to display the response as it's being generated.
sendMessageAsync(contents): Flow<Message>: Asynchronous call that returns a Kotlin Flow for streaming responses. This is the recommended approach for Coroutine users.

Synchronous Example:

import com.google.ai.edge.litertlm.Content
import com.google.ai.edge.litertlm.Message

print(conversation.sendMessage("What is the capital of France?"))

Asynchronous Example with callback:

Use sendMessageAsync to send a message to the model and receive responses through a callback.

import com.google.ai.edge.litertlm.Content
import com.google.ai.edge.litertlm.Message
import com.google.ai.edge.litertlm.MessageCallback
import java.util.concurrent.CountDownLatch
import java.util.concurrent.TimeUnit

val callback = object : MessageCallback {
    override fun onMessage(message: Message) {
        print(message)
    }

    override fun onDone() {
        // Streaming completed
    }

    override fun onError(throwable: Throwable) {
        // Error during streaming
    }
}

conversation.sendMessageAsync("What is the capital of France?", callback)

Asynchronous Example with Flow:

Use sendMessageAsync (without the callback arg) to send a message to the model and receive responses through a Kotlin Flow.

import com.google.ai.edge.litertlm.Content
import com.google.ai.edge.litertlm.Message
import kotlinx.coroutines.flow.catch
import kotlinx.coroutines.launch

// Within a coroutine scope
conversation.sendMessageAsync("What is the capital of France?")
    .catch { ... } // Error during streaming
    .collect { print(it.toString()) }

5. Multi-Modality

Message objects can contain different types of Content, including Text, ImageBytes, ImageFile, and AudioBytes, AudioFile.

// Initialize the `visionBackend` and/or the `audioBackend`
val engineConfig = EngineConfig(
    modelPath = "/path/to/your/model.litertlm", // Replace with your model path
    backend = Backend.CPU(), // Or Backend.GPU() or Backend.NPU(...)
    visionBackend = Backend.GPU(), // Or Backend.NPU(...)
    audioBackend = Backend.CPU(), // Or Backend.NPU(...)
)

// Sends a message with multi-modality.
// See the Content class for other variants.
conversation.sendMessage(Contents.of(
    Content.ImageFile("/path/to/image"),
    Content.AudioBytes(audioBytes), // ByteArray of the audio
    Content.Text("Describe this image and audio."),
))

6. Defining and Using Tools

There are two ways to define tools:

With Kotlin functions (recommended for most cases)
With Open API specification (full control of the tool spec and execution)

Defining Tools with Kotlin Functions

You can define custom Kotlin functions as tools that the model can call to perform actions or fetch information.

Create a class implementing ToolSet and annotate methods with @Tool and parameters with @ToolParam.

import com.google.ai.edge.litertlm.Tool
import com.google.ai.edge.litertlm.ToolParam

class SampleToolSet: ToolSet {
    @Tool(description = "Get the current weather for a city")
    fun getCurrentWeather(
        @ToolParam(description = "The city name, e.g., San Francisco") city: String,
        @ToolParam(description = "Optional country code, e.g., US") country: String? = null,
        @ToolParam(description = "Temperature unit (celsius or fahrenheit). Default: celsius") unit: String = "celsius"
    ): Map<String, Any> {
        // In a real application, you would call a weather API here
        return mapOf("temperature" to 25, "unit" to  unit, "condition" to "Sunny")
    }

    @Tool(description = "Get the sum of a list of numbers.")
    fun sum(
        @ToolParam(description = "The numbers, could be floating point.") numbers: List<Double>,
    ): Double {
        return numbers.sum()
    }
}

Behind the scenes, the API inspects these annotations and the function signature to generate an OpenAPI-style schema. This schema describes the tool's functionality, parameters (including their types and descriptions from @ToolParam), and return type to the language model.

Parameter Types

The types for parameters annotated with @ToolParam can be String, Int, Boolean, Float, Double, or a List of these types (e.g., List<String>). Use nullable types (e.g., String?) to indicate nullable parameters. Set a default value to indicate that the parameter is optional, and mention the default value in the description in @ToolParam.

Return Type

The return type of your tool function can be any Kotlin type. The result will be converted to a JSON element before being sent back to the model.

List types are converted to JSON arrays.
Map types are converted to JSON objects.
Primitive types (String, Number, Boolean) are converted to the corresponding JSON primitive.
Other types are converted to strings with the toString() method.

For structured data, returning Map or a data class that will be converted to a JSON object is recommended.

Defining Tools with OpenAPI Specification

Alternatively, you can define a tool by implementing the OpenApiTool class and providing the tool's description as a JSON string conforming to the Open API specification. This method is useful if you already have an OpenAPI schema for your tool or if you need fine-grained control over the tool's definition.

import com.google.ai.edge.litertlm.OpenApiTool

class SampleOpenApiTool : OpenApiTool {

    override fun getToolDescriptionJsonString(): String {
        return """
        {
          "name": "addition",
          "description": "Add all numbers.",
          "parameters": {
            "type": "object",
            "properties": {
              "numbers": {
                "type": "array",
                "items": {
                  "type": "number"
                }
              },
              "description": "The list of numbers to sum."
            },
            "required": [
              "numbers"
            ]
          }
        }
        """.trimIndent() // Tip: trim to save tokens
    }

    override fun execute(paramsJsonString: String): String {
        // Parse paramsJsonString with your choice of parser/deserializer and
        // execute the tool.

        // Return the result as a JSON string
        return """{"result": 1.4142}"""
    }
}

Registering Tools

Include instances of your tools in the ConversationConfig.

val conversation = engine.createConversation(
    ConversationConfig(
        tools = listOf(
            tool(SampleToolSet()),
            tool(SampleOpenApiTool()),
        ),
        // ... other configs
    )
)

// Send messages that might trigger the tool
conversation.sendMessageAsync("What's the weather like in London?", callback)

The model will decide when to call the tool based on the conversation. The results from the tool execution are automatically sent back to the model to generate the final response.

Manual Tool Calling

By default, tool calls generated by the model are automatically executed by LiteRT-LM and the results from the tool execution are automatically sent back to the model to generate the next response.

If you want to manually execute tools and send results back to the model, you can set automaticToolCalling in ConversationConfig to false.

val conversation = engine.createConversation(
    ConversationConfig(
        tools = listOf(
            tool(SampleOpenApiTool()),
        ),
        automaticToolCalling = false,
    )
)

If you disable automatic tool calling, you will need to manually execute tools and send results back to the model in your application code. The execute method of OpenApiTool will not be called automatically when automaticToolCalling is set to false.

// Send a message that triggers a tool call.
val responseMessage = conversation.sendMessage("What's the weather like in London?")

// The model returns a Message with `toolCalls` populated.
if (responseMessage.toolCalls.isNotEmpty()) {
    val toolResponses = mutableListOf<Content.ToolResponse>()
    // There can be multiple tool calls in a single response.
    for (toolCall in responseMessage.toolCalls) {
        println("Model wants to call: ${toolCall.name} with arguments: ${toolCall.arguments}")

        // Execute the tool manually with your own logic. `executeTool` is just an example here.
        val toolResponseJson = executeTool(toolCall.name, toolCall.arguments)

        // Collect tool responses.
        toolResponses.add(Content.ToolResponse(toolCall.name, toolResponseJson))
    }

    // Use Message.tool to create the tool response message.
    val toolResponseMessage = Message.tool(Contents.of(toolResponses))

    // Send the tool response message to the model.
    val finalMessage = conversation.sendMessage(toolResponseMessage)
    println("Final answer: ${finalMessage.text}") // e.g., "The weather in London is 25c."
}

Example

To try out tool use, clone the repo and run with example/ToolMain.kt:

bazel run -c opt //kotlin/java/com/google/ai/edge/litertlm/example:tool -- <abs_model_path>

Error Handling

API methods can throw LiteRtLmJniException for errors from the native layer or standard Kotlin exceptions like IllegalStateException for lifecycle issues. Always wrap API calls in try-catch blocks. The onError callback in MessageCallback will also report errors during asynchronous operations.
